Technical Parameters
| Parameter | AB15 | AB20 | AB30 | AB50 | AB60 | AB120 | AB200 |
|---|---|---|---|---|---|---|---|
| Apply To(ton) | 1-1.5 | 2---3 | 3---4 | 5---6 | 6---8 | 10--15 | 18-22 |
| Workflow (L/min) | 15-20 | 15-20 | 20-25 | 25-30 | 30-35 | 60-65 | 80-100 |
| Working Pressure (MPa) | 16 | 16 | 16 | 18 | 20 | 22 | 22-23 |
| Max Opening (mm) | 207 | 288 | 284 | 447 | 635 | 760 | 666 |
| Weight (kg) | 80 | 92 | 130 | 248 | 315 | 740 | 1305 |
| Dimensions (mm) | 580*450*465 | 655*500*535 | 755*500*655 | 965*600*840 | 1125*700*955 | 1260*900*1185 | 1510*1100*1300 |
Product Introduction
Application Scopes
Excavator material handling, grading, dozing, loading, backfilling, land clearing, construction sites.
Core Strengths
✅ Multi-functional 4-in-1 bucket: dozing, grading, loading and grabbing
✅ Seven models: AB15 to AB200
✅ Compatible with 1-22 ton excavators
✅ 16-23MPa working pressure
✅ 15-100 L/min hydraulic flow
✅ 207-760mm max opening
✅ Heavy-duty steel construction
✅ Hydraulic cylinder for reliable operation
✅ Ideal for versatile excavator work
Our Services
Pre‑sales Consultation
Customized model matching & tailored technical proposals
Installation Guidance
Custom‑fit installation tips & optional on‑site commissioning
Warranty Service
Warranty‑covered repair & customized spare‑parts supply
24/7 Tech Support
Targeted remote assistance & on‑site solutions on demand
FAQ
What is the warranty period?
Standard warranty coverage is offered for all products, extended warranty options are also available upon request.
Do you provide installation services?
Yes, we can provide remote commissioning and operation‑training support for your team.
How long does shipping take?
Delivery lead time depends on order quantity and product types. Expedited shipping service is available with additional charges.
Do you support product customization?
Yes, custom solutions are available. Please get in touch with our sales team for detailed requirements.
Can I get a customized model?
Absolutely. We support OEM / ODM customization services. Feel free to consult our sales team for more details.
