Technical Parameters
| Parameter | 8T | 15T | 20T |
|---|---|---|---|
| Apply to(t) | 8T | 15T | 20T |
| Weight (kg) | ≈760 | ≈1080 | ≈1750 |
| Vibration Frequency (Hz) | 13～75 | 18～75 | 18～75 |
| Oil Flow(L/min) | 45-50 | 100-110 | 140-160 |
| Working Pressure(MPa) | 18-20 | 22 | 25 |
| Sieve Hole Sizes(mm) Optional | 50×50 | 50×50 | 50×50 |
| Dimensions - Length(mm) | 1125 | 1300 | 1540 |
| Dimensions - Width(mm) | 900 | 1200 | 1550 |
| Dimensions - Heigh(mm) | 1145 | 1235 | 1460 |
Product Introduction
Application Scopes
Soil screening, aggregate separation, construction waste sorting, topsoil processing, landscaping, material classification, river dredging.
Core Strengths
✅ Hydraulic vibratory screening bucket for excavators
✅ Three models: 8T, 15T, 20T
✅ Compatible with 8-20 ton excavators
✅ 13-75 Hz vibration frequency
✅ 18-25MPa working pressure
✅ 45-160 L/min hydraulic flow
✅ 50×50mm sieve hole size (optional)
✅ Heavy-duty grid construction
✅ Ideal for soil and aggregate screening
Our Services
Pre‑sales Consultation
Customized model matching & tailored technical proposals
Installation Guidance
Custom‑fit installation tips & optional on‑site commissioning
Warranty Service
Warranty‑covered repair & customized spare‑parts supply
24/7 Tech Support
Targeted remote assistance & on‑site solutions on demand
FAQ
What is the warranty period?
Standard warranty coverage is offered for all products, extended warranty options are also available upon request.
Do you provide installation services?
Yes, we can provide remote commissioning and operation‑training support for your team.
How long does shipping take?
Delivery lead time depends on order quantity and product types. Expedited shipping service is available with additional charges.
Do you support product customization?
Yes, custom solutions are available. Please get in touch with our sales team for detailed requirements.
Can I get a customized model?
Absolutely. We support OEM / ODM customization services. Feel free to consult our sales team for more details.
