Technical Parameters
| Parameter | SB-135 | SB-175 |
|---|---|---|
| Tractor Mounting | CAT-1 | CAT-2 |
| Auxiliary Hydraulic | 2 pcs double acting | 2 pcs double acting |
| PTO Speed | (540)/1000 rpm | (540)/1000 rpm |
| Power Range | 50-90 hp | 70-180 hp |
| Transmission | Mechanical PTO | Mechanical PTO |
| Final Transmission | Chain 2-row | Chain 2-row |
| Clutch | POC-2 | POC-2 |
| Rotor Diameter | 400mm | 400mm |
| Working Width | 1350mm | 1750mm |
| Cutter Quantity | 60 (T25 Rotor) | 76 (T25 Rotor) |
| Working Depth | 200mm | 200mm |
| Length | 1550mm | 1550mm |
| Width | 1800mm | 2200mm |
| Height | 1010mm | 1220mm |
| Weight | 710 kg | 970-1060 kg |
| Weight with Options | 1050 kg | 1390-1480 kg |
Product Introduction
Application Scopes
Farmland preparation, stone crushing, soil cultivation, wasteland reclamation, vegetation management, organic farming, pasture renovation.
Core Strengths
✅ Multi-function stone crusher and cultivator in one
✅ Two working widths: 1350mm and 1750mm
✅ 60-76 heavy-duty T25 rotor cutters
✅ 200mm working depth for deep cultivation
✅ PTO-driven, 540/1000 RPM
✅ Compatible with 50-180 HP tractors
✅ CAT-1/CAT-2 mounting options
✅ Durable chain 2-row transmission
✅ Ideal for soil preparation and stone crushing
Our Services
Pre‑sales Consultation
Customized model matching & tailored technical proposals
Installation Guidance
Custom‑fit installation tips & optional on‑site commissioning
Warranty Service
Warranty‑covered repair & customized spare‑parts supply
24/7 Tech Support
Targeted remote assistance & on‑site solutions on demand
FAQ
What is the warranty period?
Standard warranty coverage is offered for all products, extended warranty options are also available upon request.
Do you provide installation services?
Yes, we can provide remote commissioning and operation‑training support for your team.
How long does shipping take?
Delivery lead time depends on order quantity and product types. Expedited shipping service is available with additional charges.
Do you support product customization?
Yes, custom solutions are available. Please get in touch with our sales team for detailed requirements.
Can I get a customized model?
Absolutely. We support OEM / ODM customization services. Feel free to consult our sales team for more details.
