Technical Parameters
| Parameter | MSB01 | MSB02 | MSB08 | MSB12 | MSB16 | MSB18 | MSB20 |
|---|---|---|---|---|---|---|---|
| Machine Class(t) | 1.2-2.5 | 2.5-5.5 | 6--8 | 10--18 | 19-28 | 29-38 | 40-50 |
| Rotary Screen Diameter(mm) | 500 | 592 | 700 | 1005 | 1420 | 1470 | 1700 |
| Rotating Speed(r/min) | 30-35 | 30-35 | 35-40 | 30-35 | 30-35 | 35-45 | 35-45 |
| Working Pressure(MPa) | 10--12 | 10---12 | 12--15 | 18-21 | 18-22 | 20-23 | 20-23 |
| Oil Flow(L/min) | 18-20 | 18-20 | 40-45 | 90-100 | 90-100 | 90-100 | 100-150 |
| Weight(kg) | 150 | 260 | 515 | 965 | 1700 | 2800 | 4080 |
Product Introduction
Application Scopes
Soil screening, aggregate separation, construction waste sorting, topsoil processing, landscaping, river dredging, material classification.
Core Strengths
✅ Hydraulic rotary screening bucket for excavators
✅ Seven models: MSB01 to MSB20
✅ Compatible with 1.2-50 ton excavators
✅ 500-1700mm rotary screen diameter
✅ 30-45 RPM rotating speed
✅ 10-23MPa working pressure
✅ Efficient material screening and separation
✅ Durable construction for heavy-duty use
✅ Ideal for soil and aggregate screening
Our Services
Pre‑sales Consultation
Customized model matching & tailored technical proposals
Installation Guidance
Custom‑fit installation tips & optional on‑site commissioning
Warranty Service
Warranty‑covered repair & customized spare‑parts supply
24/7 Tech Support
Targeted remote assistance & on‑site solutions on demand
FAQ
What is the warranty period?
Standard warranty coverage is offered for all products, extended warranty options are also available upon request.
Do you provide installation services?
Yes, we can provide remote commissioning and operation‑training support for your team.
How long does shipping take?
Delivery lead time depends on order quantity and product types. Expedited shipping service is available with additional charges.
Do you support product customization?
Yes, custom solutions are available. Please get in touch with our sales team for detailed requirements.
Can I get a customized model?
Absolutely. We support OEM / ODM customization services. Feel free to consult our sales team for more details.
